Fiber Wood Insulation Roof dry 140kg/m³

Fiber Wood Insulation FiberTherm Roof dry with density of 140kg/m³

Fiber Wood panels with a density of 140 Kg/m³.
Fibertherm Roof dry 140 is a fiber wood panel for thermal insulation for ceilings and flat or pitched roofs. Ideal for roof insulation in wooden buildings, but also in renovations and new traditional buildings.

The Fiber Wood panel FiberTherm Roof dry 140 is a thermal insulator for extrados of floors and pitched roofs or flat roofs.

The fiber wood panels FiberTherm Roof dry 140 are ideal to insulate flat roofs. They have a density equal to 140kg/m³ and provide an high security due to their water repellent properties.

The material is also recyclable, it is certified and made exclusively with wood from controlled forests in compliance with the FSC guidelines (Forest Stewardship Declaration).


The insulating fiber wood panels FiberTherm Roof dry 140 has the following characteristics:

• ideal for the insulation of flat roofs;
• very good thermal insulation in winter and summer;
• high compressive strength;
• high safety for water repellent properties;
• recyclable, ecologic, environment-friendly;
• building material tested and authorized according to current European standards.

Available sizes

fiber wood panels with sharp edges
Thickness Size mm kg/m² Pan./pallet m²/pallet kg/pallet
60 mm 800 x 800 8,40 38 24,3 approx.237
80 mm 800 x 800 11,20 28 17,9 approx.228
100 mm 800 x 800 14,00 22 14,1 approx.216
120 mm 800 x 800 16,80 18 11,5 approx.209
140 mm 800 x 800 19,60 16 10,2 approx.214
160 mm 800 x 800 22,40 14 9,0 approx.213
180 mm 800 x 800 25,20 12 7,7 approx.204
200 mm 800 x 800 28,00 12 7,7 approx.225


Technical characteristics

Characteristics Values
Density kg/m³ 140
Fire reaction according to EN 13501-1 E
Coefficient of thermal conductivity λD W/(m∗K) 0,040
Specific heat J/(kg∗K) 2.100
Resistance to vapor diffusion μ 5
sd value (m) 0,18(60)/0,24(80)/0,30(100)/
0,36(120)/ 0,42(140)/0,48(160)/
0,54(180)/ 0,60(200)
Thermal resistance RD (m²·K)/W 1,50(60)/2,00(80)/2,50(100)
/3,00(120)/ 3,50(140)/4,00(160)/
4,50(180)/ 5,00(200)
Compression stress
for 10% of distorsion (N/mm²)
0,1
Compression resistance (kPa) 100
Tensile resistance (kPa) ≥10
Resistance to airflow [(kPa·s)m²] ≥100
Panels identification WF-EN 13171-T5
–DS(70/-)2–CS(10\Y)100-
TR10–WS1,0–MU3
Waste code (EAK) 030105/170201


Solutions with Fiber Wood Roof

Dry screed in Fiber Wood Roof and cement bonded particle board
Dry screed in Fiber Wood Roof and cement bonded particle board

Dry system for thermal insulation of floors in fiber wood FiberTherm Roof and cement bonded particle boards BetonWood for an excellent thermal displacement.

SEE MORE
Dry screed in Fiber Wood Roof on concrete
Dry screed in Fiber Wood Roof on concrete

Dry system for thermal insulation of floors and attics with double layer of fiber wood FiberTherm Roof on concrete support.

SEE MORE
Dry screed in Fiber Wood Roof on terracotta tiles
Dry screed in Fiber Wood Roof on terracotta tiles

Dry system for thermal insulation of floors and attics with double layer of fiber wood FiberTherm Roof on terracotta tiles.

SEE MORE
Dry screed in Fiber Wood Roof on wood
Dry screed in Fiber Wood Roof in wood

Dry system for thermal insulation of floors and attics with double layer of fiber wood FiberTherm Roof on wood.

SEE MORE
Ventilated roof with Fiber Wood Therm on matchboarding
Ventilated roof with Fiber Wood Therm on matchboarding

Ventilated roof system with Aercoppi and high density fiber wood FiberTherm with excellent thermal insulation power on matchboarding.

SEE MORE
Ventilated roof with Fiber Wood Therm on matchboarding
Ventilated roof with Fiber Wood Therm on matchboarding

Ventilated roof system with high density and excellent thermal insulating fiber wood FiberTherm on matchboarding.

SEE MORE
Ventilated roof with Fiber Wood Therm on concrete
Ventilated roof with Fiber Wood Therm on concrete

Ventilated roof system with Aercoppi and high density fiber wood FiberTherm with excellent thermal insulation power on concrete support.

SEE MORE
Ventilated roof with fiber wood Therm on concrete
Ventilated roof with Fiber Wood Therm on concrete

Ventilated roof system with high density and excellent thermal insulating fiber wood FiberTherm on concrete support.

SEE MORE
Ventilated roof with Fiber Wood Therm on terracotta tiles
Ventilated roof with Fiber Wood Therm on terracotta tiles

Ventilated roof system with Aercoppi and high density fiber wood FiberTherm with excellent thermal insulation power on terracotta tiles.

SEE MORE
Insulating roof in Fiber Wood Therm
Insulating roof in Fiber Wood Therm

High insulating roof in fiber wood panels FiberTherm Therm fixed on metal or wooden frame and covered with plasterboards.

SEE MORE
